The goal of this lab is to introduce you to basic concepts in the C++ program language. Concepts you will be familiar with after this lab include:

• basic user input/output (i.e., cin, cout)
• file input and output (using the fstream library)
• function declarations, definitions, and calls
• managing arrays, including passing to functions
• for loops
• defensive programming (e.g., detecting improper input)

In addition, you will become somewhat familiar with image processing and the concept of buffering.

A skeleton version the program will appear in your cs35/labs/01 directory when you run update35. The program handin35 will only submit files in this directory. In later labs you may have the opportunity to work with a partner, but for this lab you should work on your own. Useful links:

• The PPM Image format
• Sample output

This lab will have you write a program to load and output image files. In addition, you will provide a user the option to perform some basic image manipulation, including color alteration and horizontal flipping. To begin, we will first learn about the PPM Image format. Click here for information about the PPM format (and how to parse it) as well as tips for viewing and creating PPM image files.

Reading about the PPM format may seem overwhelming, but it's actually fairly simple to get started. At a high level, your program will ask the user to provide both the name of the input PPM image and the name of the file they would like to save the modified PPM to. You will then ask the user which of several image alteration techniques they would like to apply, perform the operations, and save the resulting image.

An aside: compiling your program in lab 1 is a little different from last lab. In this lab, your image manupulation function declarations/definitions will be split into separate helper files ppmEditorHelper.h and ppmEditorHelper.cpp. You must put your image manipulation functions in this file. To make sure C++ knows where to get the code for these functions, you need to include it in the compilation command, like this:

$ g++ -o ppmEditor ppmEditor.cpp ppmEditorHelper.cpp

Here is a sample run of the program where the only options are to convert an image to greyscale and flip it horizontally:

$ g++ -o ppmEditor ppmEditor.cpp ppmEditorHelper.cpp
$ ./ppmEditor

Welcome to the Portable Pixmap (PPM) Image Editor

Enter name of image file: input/machupicchu.ppm
Enter name of output file: machupicchu-grey.ppm
Do you want to:
	convert to greyscale? (y/n): y
	flip horizontally? (y/n): n

Session complete

The original and resulting image:

machupicchu.ppm	machupicchu-grey.ppm

I recommend implementing your program in 3 phases:

1. File Input and Output - be able to read in a PPM image and output it without loss of information
2. Image alteration functions - add functions for modifying the image. You must put the function declarations for your image alteration functions in ppmEditorHelper.h and the function definitions in ppmEditorHelper.cpp. We have created some function declarations for you already.
3. Bring it all together with a menu - complete your program by adding user interaction to choose which image filters to apply to an image

Your program should use proper design. That is, your program will be tested on your use of modular functions and understanding of how to call, define, and declare functions in C++.

---

I. File Input and Output

Your program will need to handle opening, reading, closing, and writing to file.

• The user will specify the name of the image file. The file will be a text file in PPM format as described in the discussion above. To open an input file, use the ifstream data type.

          string inputfilename = "image.ppm"; //Get this from the user
          ifstream inputFile(inputfilename.c_str());


• To read from the input file, treat inputFile the same as cin . You can read in any basic type, such as strings and integers. The >> operator parses text by reading all characters until whitespace is found. It will also ignore all preceding whitespace. For example, to read the lines:

  	hungry
  	356     blue


  You can use the code:

  	string verb, color;
  	int number;
  	input >> verb;   //"hungry"
  	input >> number; //356
  	input >> color;  //"blue"


  Notice that the strings do not contain whitespace, and that it automatically skipped the whitespace between 356 and blue. The provided code shows how to read the first two lines of the PPM file, you will need to complete the rest.


• If you are using a loop to read from a file, you may need to know if the file still has data to read. Use the eof() function to do this. That is, if input.eof() returns true, you have reached the end of the file and should not continue. Depending on your algorithm, this may not be necessary.


• The user will specify an output filename. Opening this is similar to the example above, except you will use the ofstream data type. Details on file i/o can be found here. Here is an example of loading an output file and writing the variables above:

  	string outName = "output.txt";
  	ofstream outputFile(outName.c_str());
  	output << verb << endl;
  	output << number << "   " << color << endl;


• For this first phase, your goal is to make an exact copy of the input file as the output file. The catch is that you are limited to only one buffer array which is 3000 integers long (i.e., represent 1000 pixels). You will not be able to read all of the image into memory at one time. So you have to deal with one piece of the file at a time. To keep things simple, you should check the input file to make sure it's width is less than 1000 pixels (abort if it is too big).

  To help read a line of pixels write a function readLine with the following signature:

  	bool readLine(ifstream& input, int pixels[], int columns)


  that takes in the input file, your buffer array, and the number of columns for one line of the image. Your function should read one line of the image (NOT necessarily one line of the file) and load the values into the pixels buffer. Note that arrays in C++ are passed-by-pointer, so any modifications to pixels will modify the array designed in the call to readLine (just like in Python!). Your method should return whether the input stream is still valid (HINT: inputFile.good() returns true if everything is in the clear). Your main program should stop if a read fails, output an error message, and quit.

  Create a corresponding function for writing one line of data:

  	void writeLine(ofstream& output, int pixels[], int columns)


• With your buffer, input, and output files established, have your main method read in one buffer full, write it out to the output file, and repeat the process until the input is exhausted. Test it out on an image, does the output image look the same?

Your output file can actually be formatted as you like. Whitespace includes newline characters, so you can put them in where you wish. The format allows for it. Test this with small files and large files. You can check to see if they are identical by loading them both into a text editor like gvim and comparing number by number. Load them into image viewers, as discussed in the PPM Image Format help page listed above. Example ppm files are available in the input folder in your labs directory for this week.

• cake.ppm - A picture of a slice of cake on a plate
• squares.ppm - Some boxes
• blocks.ppm - Some solid blocks of color
• tinypix.ppm - The example image from above

Review of requirements before moving forward:

• Check if input file opened properly
• Read header information, output to file
• Abort if image is too wide
• Implement readLine, reading one line of pixels at a time
• Loops reads all lines of the file
• Check state of input stream after each call to readLine
• Implement writeLine to output one line of pixels to the output file
• All files are closed when no longer used
• Test program: output file should match input

---

II. Image Alteration Functions

Once you can exactly replicate a PPM image, you can begin writing functions to manipulate the image. At a minimum, you must implement a function to convert an image to greyscale, another to flip the image horizontally, a method to negate all red values, and at least 2 more of your choosing. Let us begin with negating red values.

• Write a function called negateRed.

  	void negateRed(int pixels [], int columns, int maxColorValue)


  It will change just the red color numbers into their "negative". That is, if the red number is low, it should become high and vice versa. This depends on the maximum color value. For example, if maximum value is 255 and a pixel had a red value of 0, it would become 255; if it were 255 it would become 0. If the red were 100, it would become 155. It should make changes to the buffer array as described above.


• When you have this function written, insert it into Phase I so that every pixel of the picture has had its red color negated in the output file.


• View this picture - does it look as you expected?


• Write a function called flipHorizontally.

  	  void flipHorizontally(int pixels[], int columns);


  This function will flip the picture horizontally. That is, the pixel that is on the far right end of the row ends up on the far left of the row and vice versa (remember to preserve RGB order!). This is probably the trickiest of all of image alteration functions, so be sure to think about this carefully and test often.


• Write a function called greyScale,

  	  void greyScale(int pixels[], int columns);


  which will change the picture into a grey scale image. This is done by averaging the values of all three color numbers for a pixel, the red, green and blue, and then replacing them all by that average. So if the three colors were 25, 75 and 250, the average would be 116, and all three numbers would become 116.

Pick whatever sounds interesting for your other methods. Some ideas include:

• negateGreen - negate the green number of each pixel.
• negateBlue - as above but change the blue
• flattenRed - sets the red value to zero
• flattenGreen - sets the green value to zero
• flattenBlue - sets the blue value to zero
• extremeContrast - push all RGB values to 0 or the maximum value; e.g., anything lower than 128 becomes 0 and everything above to 255. This decision is independent for each color channel.
• horizontal_blur - takes the value of the red numbers of three adjacent pixels and replace them with their average. It also does the same with the greens and the blues of 3 adjacent pixels. Pixels on the edges will have to be handled specially. Note that this is not the same as greyscale conversion.

Note that you are responsible for determining what parameters are needed for each of these functions (aside from negateRed, flipHorizontally, greyScale which have been provided for you. A more difficult but fun function would be to add random noise to the image. There is plenty of information on how to generate random values in C++ online, or you can come see me or one of the ninjas.

---

III. Bring it all together with a menu

The overall design of your program should be as follows:

Greet user
Ask user for input file (check if valid)
Ask user for output file
Read header (check if valid)
Output header
Ask user what filters (image alterations) to apply
For each line of the image:
	Load image into buffer (check if still in valid state)
	Apply chosen filters
	Write image to output file
Close files, output message

The menu simply asks the user if they would like to apply each filter you developed. Using a series of yes or no questions. If the user enters an invalid value (you must define this) you should restate the question until a valid response is provided. At all points in your program, you should be defensive against potential user error

See the example at the top of the writeup for an example menu. Your program should apply each filter specified, in succession, one at a time. The filters must be cumulative (even if doesn't make sense in some cases); that is, if the user chooses to flatten all reds and flatten all blues, you should have a resulting picture of only green values.

• Are you validating user input?
• Implement at least 5 filter methods (including the three required methods).
• Your program must use good design. Main should be fairly simple, calling on other methods to perform work. The exception (for this lab) is that opening files and reading/writing the header can be done in main. All other file i/o and user interaction must be done within their respective methods.
• All functions must have a top header comment that includes the functions name, purpose, parameter descriptions, and expected return values if any
• All significant portions of code and non-trivial code should have a comment explaining purpose
• All image filter functions must be declared in ppmEditorHelper.h and defined in ppmEditorHelper.cpp.
• All other functions must be declared before main, but defined after main

You can find examples of the cake image here.

Once you are satisfied with your code, hand it in by typing handin35. This will copy the code from your cs35/labs/01 to my grading directory. You may run handin35 as many times as you like, and only the most recent submission will be recorded.

This lab write up is based off of Joshua Guerin and Debby Keen's NIFTY 2012 submission titled PPM Image Editor.
